Parallel Pins,Of Unhardened Steel And Austenitic Stainless Steel

Home - Products - Security Fasteners - Parallel Pins,Of Unhardened Steel And Austenitic Stainless Steel
64dd916d7f771

Parallel Pins,Of Unhardened Steel And Austenitic Stainless Steel

Material: Steel hardness 125~245 HV30, Austenitic stainless steel A1 (ISO 3506-1) hardness 210~280 HV30.

Standard: ISO 2338, ISO 8734, DIN 7, DIN 6325, DIN EN ISO 8734 - 2019, ASME B 18.8.2 - 2020, Q521

Inquire Now Next Products

Product Specification

Material: Steel hardness 125~245 HV30, Austenitic stainless steel A1 (ISO 3506-1) hardness 210~280 HV30.

Surface Finish： Plain, i.e. pins to be supplied in natural finish treated with a protective lubricant, unless otherwise specified by agreement between customer and supplier. Preferred coatings are black oxide， phosphate coating, or zinc plating with chromate conversion coating ( see ISO 9717 and ISO 4042 ). Other coatings as agreed between customer and supplier. All tolerances shall apply prior to the application of a plating or coating. Plain, i.e. pins to be supplied in natural finish.

Surface roughness: Tolerance m6: Ra≤0.8 µm, Tolerance h8: Ra≤1.6 µm.

Surface defects: Irregular and harmful defects are not allowed. There shall be no burrs on any part of the pin.


Size Can also be According to the Customer's requirement for manufacturing, please check the detailed specification sheet details PDF, CAD, 5-6Page See more product details.

ProductPackaging

Packaging: The inner packaging is a plastic bag, and the outer packaging is a carton. Then the tray. Carton size: 29*19*19.5CM and 23.5*17.5*8CM and pallet size: 215*100*90CM, or as your request.

ProductPictures

Parallel Pins,Of Unhardened Steel And Austenitic Stainless Steel

Parallel Pins,Of Unhardened Steel And Austenitic Stainless Steel
