Name: Weld Standoffs
Material: Stainless steel, Carbon steel.Aluminum, Brass
1. Compared with general arc welding, stud welding has a shorter welding time and less energy input to the base metal, so the weld metal and heat-affected zone are narrow, and the deformation of the weldment is small.
2. The productivity of stud welding is high, and the welding time usually does not exceed 1s.
3. The use of stud welding can not only save materials but also reduce the machining and welding workload required for connecting parts.
Pins from Ø3 to Ø7.1 in steel, stainless steel A2-50, and AlMg3 are stocked in all standard lengths and can be delivered quickly.
Custom lengths and other materials are also produced to order.
The following dimensions can generally be produced:
Ø2 x 5 to 25 mm
Ø3 x 5 to 40 mm
Ø4 x 6 to 45 mm
Ø5 x 6 to 70 mm
Ø6 x 8 to 75 mm
Ø7.1 x 10 to 75 mm
Ø8 x 15 to 75 mm
Ø10 x 15 to 75 mm
Ø12 x 15 to 75 mm
Size Can also be According to the Customer's requirement for manufacturing, please check the detailed specification sheet details PDF, CAD, 147-148 Page See more product details.
