Spring Threaded inserts tube Star Insert Nuts Plum shrapnel nut&Tube-Connecting Nuts

Material:Steel+65Mn

Inquire Now Next Products

Product Specification

Tube-Connecting Nuts. Create strong joints in metal and plastic round tubes. Clips on both ends grip the sides of the tube to hold the nut in place. A zinc plating provides corrosion resistance in wet environments.Drawings and images are for reference only and should not be used for product specifications. For new applications, we recommend that you carry out assembly tests using samples supplied by us.


The Tube Connector Nut, also known as a Star Fangled Nut, is an innovative method for creating a threaded hole in tubes. It eliminates the need for other more costly methods such as welding or flow drilling. This allows the attachment of a wide range of threaded rod components to tubes.
The Connector Nut is simply pushed into the tube (direction shown below) where it provides a threaded anchor for the mating component.
• Innovative
• Cost saving
• Fits round tubes
D = Outer diameter of tube.
D1 = Approximate inner tube diameter
Materials - Austempered Carbon Steel (Retainer), Mild Steel (Thread)


Size Can also be According to the Customer's requirement please check the detailed specification sheet details PDF， CAD, 85-86 Page See more product details.


ProductPackaging

Packing: The inner packaging consists of polyfoam, while the outer layer is a carton. The carton sizes are 29*19*19.5 cm and 23.5*17.5*8 cm, respectively. The pallet dimensions are 215*100*90 cm, or they can be customized according to your requirements.

ProductPictures

Spring Threaded inserts tube Star Insert Nuts Plum shrapnel nut
