Screw Fastened PCB Support JX-1103-CS&Reverse Locking Spacer

Home - Products - Blind Rivets Nuts & Stud Fasteners for Sheet Metal - other - Screw Fastened PCB Support JX-1103-CS&Reverse Locking Spacer
68a915dd1f807

Screw Fastened PCB Support JX-1103-CS&Reverse Locking Spacer

Name: Reverse Locking Spacer, PCB Support - Spacer, Reverse Locking Support, Flat Top, Designed To Hold Heavy Boards, Push Spacer

Usage: First, drill 5.5mm holes in the substrate, then push the isolation column from the bottom to fix it, and then fix the PC board.

Features: PC board can be fixed without tools; easy to disassemble when replacing or repairing PC board.

This is a push-reverse locking spacer with a flat top mounted on the underside of the board. It is designed to fit through the bottom of a PCB and connect to the panel above.

Our wide range of PCB accessories offers an extensive selection of PCB Spacers, pillars, supports, and standoffs to support, lock, space, or guide the PCB board.

Discover accessories for appliances (white goods), electrical cabinets, machinery, or other PCB support equipment.


Inquire Now Next Products

Product Specification

Snap-In Supports with Female Connection

Material: PC board isolation column PS type. Qualified NYLON66 (natural color), fire rating 94V-2, not easy to age, high insulation.

Usage: Drill 4.8mm holes in the base plate first, then insert the isolation column into the base plate hole.

Usage: Support the PC board and increase its stability of PC board.

Secure the self-tapping female connection with a screw; the other end snaps snugly into a board yet can be released for repairs and upgrades. Supports are nylon, which has excellent wear and abrasion resistance and offers resistance to chemicals and solvents (except mineral acids). Exposure to moisture may cause them to expand.


ProductPictures

Screw Fastened PCB Support JX-1103-CS
