Material: 35 steel, Y20, Y15, Y12
Finish: galvanized passivated, Fe/Ep-Zn5.
Tube fitting is a device used to connect pipes, also known as clamp-type pipe fitting or sleeve-type pipe fitting. The ferrule pipe fitting is composed of, a ferrule and a nut, which is a device for connecting pipes to pipes. The main function of the ferrule pipe fitting is to connect and fix two sections of pipes to ensure the sealing and solidity between the pipes. Structural development characteristics: in the assembly technology with China's advanced geometry for the design of the main features of the pipe joint (as shown in the figure on the left), the front ferrule is pushed into the joint body, and tubing can form the main seal, and the rear ferrule inward to produce a hinge is to form a strong grip on the tubing between. The geometry of the back ferrule is analyzed to help the student develop an advanced engineering hinge-holder effect that translates axial motion into radial compression on the tubing.
The double collar separates the sealing function from the clamping function of the collar, and each collar is optimized for its respective function. The front collar is used to form a seal: against the joint body against the outer diameter of the collar. When the nut is rotated, the rear collar will advance the front collar axially. Apply an effective collar clamping force in the radial direction.
Size Can also be According to the Customer's requirement please check the detailed specification sheet details PDF， CAD, 99-100 Page See more product details.
