Mini Dual Locking Support Post JX-GSP

Home - Products - Blind Rivets Nuts & Stud Fasteners for Sheet Metal - other - Mini Dual Locking Support Post JX-GSP
68a95ac8cfd26

Mini Dual Locking Support Post JX-GSP

Name: Mini Dual Locking Support Post

Material: P.C. board isolation column JX-GSP type. Qualified NYLON66 (natural color), fire rating 94V-2, not easy to age, high degree of insulation.

Usage: It is tool-free and easy to load and unload by hand. Drill 2.0mm holes in the substrate, fix the isolation column, and insert the PP.C.board into it.

Usage: For fixing the PP.C.board.

Both ends snap and lock in place for a permanent connection. Made of nylon, these supports are excellent in wear and abrasion resistance and resist chemicals and solvents (except mineral acids). Exposure to moisture may cause them to expand.

All meet UU.L.94 flammability standards. Supports that meet UU.L.94 V-0 stop burning within 30 seconds if they catch fire, and supports that meet UU.L.94 V-2 stop burning within 10 seconds if they catch fire.

Material: PP.C.board isolation column JX-SU type. Qualified NYLON66 (natural color), fire rating 94V-2, not easy to age, high degree of insulation.


Inquire Now Next Products

Product Specification

The Nylon Dual Locking Circuit Board Support product specification chart belongs to the plastic fasteners in the hexagonal isolation column series, mainly used in electronics, computer PC boards, machine boards, and fixed roles. Material: UL-qualified NYLON66 (natural color), fire rating 94V-2; Usage: for PC boards and machine boards between the fixed, hexagonal type does not slip; Features: sound insulation, non-rust, non-corrosive, lightweight; Male-Female Threaded Standoff other vital points: ROHS compliant!

ProductPictures

Mini Dual Locking Support Post JX-GSP
