Locking Circuit Board Support Post JX-GDE09-0195

Name: Locking Circuit Board Support JX-GDE09-0195

Locking Circuit Board Support Type

PCB Support - Spacer, Locking Two Prong, Bayonet, Teardrop, Spacer, Non-Locking Extended Bayonet Arrowhead, Snap Lock, Quarter Turn, Cupped.

Material: PA66 UL94V2 (GMS-01); PA66 UL94V0 (GMS-02)

Top Hole: 4.0+0.08mm

Panel Thickness: 3.2mm

Bottom Hole: 4.8+0.08mm

Panel Thickness:2.0-3.2mm

Dual locking circuit board support is supplied in UL94 V2 nylon 6/6 RMS-01 or UL94 V0 RMS-19. It features a snap-in-fit feature that makes it easier to fit into the PCB. It provides good strength to the board and chassis and prevents rotation.

Applications and Benefits of Dual Locking Circuit Board Support

Supplied in UL94 V2 nylon 6/6 RMS-01 or UL94 V0 RMS-19.

It features a snap-in fit for easy fitting.

Provides good strength to the PCB.Prevents rotation.


Inquire Now Next Products

Product Specification

Locking Bayonet with Locking Arrowhead

These spacers have an extra-long top mounting fastening. This long nose automatically locates and aligns connector pins with the socket. The top board is also easily removable.

The locking Circuit Board Support is made from Natural Nylon 6/6 and has a non-locking extended bayonet on one side and a locking arrowhead on the opposite side.

Wings add tension to strengthen the hold in a hole. The other end is releasable for repairs and upgrades. Made of nylon, these supports have excellent wear and abrasion resistance and resist chemicals and solvents (except mineral acids). Exposure to moisture may cause them to expand.


ProductPictures

Locking Circuit Board Support Post JX-GDE09-0195
