B-type hole with elastic retaining ring specifications range:: Φ3-Φ300; heat treatment needs to be quenched and tempered, HRC 44-51 (process reference value); material to 65Mn spring steel based on the surface treatment of the product, spring steel is basically heat-treated blackened or phosphatized to ensure that the hardness, elasticity is uniform, the surface is flush and deburred. Products used in machinery, automobiles, motors, ships, and other industries. B-type holes with elastic retaining rings installed in the round hole are used to fix the axial movement of the parts, the outer diameter of such retaining ring is slightly larger than the diameter of the assembly hole. When installing, it is necessary to use the circlip pliers, insert the jaws into the jaw hole of the retaining ring, and clamp the retaining ring before it can be put into the inner groove of the pre-processed round hole.
The elastic retaining ring for a B-type hole is a kind of elastic part with a special design, which has the following characteristics:
1. Simple structure: The b-hole elastic retaining ring adopts a simple design structure, easy to install and use.
2. high elasticity: B-type hole retaining ring has good elasticity and can withstand large extrusion pressure.
3. Good sealing: B-type hole retaining rings can effectively prevent the leakage of liquid or gas.
4. Strong abrasion resistance: B-type hole retaining rings are made of wear-resistant materials, which can maintain good performance for a long time.
5. Good anti-vibration performance: B-type hole retaining ring can effectively absorb and reduce vibration, and protect equipment from damage.
Size Can also be According to the Customer's requirement please check the detailed specification sheet details PDF， CAD, 43-44 Page See more product details.
