Name: Stainless Steel Threaded Pipe and Pipe Fittings&Brass and Bronze Pipe and Pipe Fittings&Iron and Steel Threaded Pipe and Pipe Fittings
Size: DN6(1/8"), DN8(1/4"), DN10(3/8"), DN15(1/2"), DN20(3/4"), DN25(1"), DN32(1-1/4"), DN40(1-1/2"), DN50(2"), DN65(2-1/2"), DN82(3"), DN100(1-1/2")
Material: Stainless steel SUS304, SUS201, SUS316, Copper, Steel
Use these fittings for low-pressure applications in noncorrosive environments.
1. For Use With Air, Steam, Oil, Water, Natural Gas
Pressure Class: 150
Specifications Met:
NPT: ASME B1.20.1, ASME B16.3
BSPT: DIN EN 10226
Pipe Nipples and Pipe: Use Schedule 40 steel
2. For Use With Air, Natural Gas, Oil, Steam, Water
Pressure Class: 150
Fabrication: Heat Treated
Specifications Met:
NPT: ANSI/MSS SP-114, ASTM A351
BSPT: ANSI/MSS SP-114
Pipe Nipples and Pipe: Use Schedule 40 stainless steel
Flanges: Use Class 150 stainless steel
3. Use these fittings in low-pressure flow applications. They have good corrosion resistance. Fittings rated for use with drinking water meet NSF/ANSI 61 safety standards.For Use With:
NPT: Air, Drinking Water, Natural Gas, Oil
BSPT: Air, Natural Gas, Oil, Steam, Water
Pressure Class: 125
Specifications Met:
NPT: ASME B1.20.1, ASME B16.15, NSF/ANSI 61
BSPT: ASME B16.15, ASME BS21, ASTM B584
Pipe Nipples and Pipe: Use Schedule 40 brass
Flanges:
NPT: Use Class 150 brass
BSPT: Use Class 150 bronze
