JX-DIN314 Brass Square wing butterfly nut

Home - Products - Industrial Nuts— lock, flange, wheel, structural & specialty assemblies - JX-DIN314 Brass Square wing butterfly nut
641283b6877d7

JX-DIN314 Brass Square wing butterfly nut

Material: Stainless Steel

Standard: GB /T 62.1 - 2004, GB /T 62.4, GB /T 62.3, GB /T 62.2, DIN 315, ANSI/ASME B 18.6.9, JIS B 1185, Q 390B, DIN 314, ANSI/ASME B 18.6.9, JIS B 1185

Inquire Now Next Products

Product Specification

Name: Stainless steel Wing nuts

Material: Stainless Steel

Size: M4, M5, M6, M8, M10, M12, M14, M16, M18, M20

JX-DIN314 Brass Square wing butterfly nut

The application advantages of wing nuts are as follows:

1. Keep the back of the board completely flat;

2. Small and exquisite, suitable for all electronic or precision equipment;

3. High torque resistance;

4. It is easy to equip, and only needs simple pressure riveting;

5. Serialization of specifications can meet various design requirements.

Made from 18-8 stainless steel, these nuts have good chemical resistance and may be mildly magnetic. The wings provide more leverage for greater torque while tightening than knurled-head thumb nuts.

JX-DIN314 Brass Square wing butterfly nut


Size Can also be According to the Customer's requirement please check the detailed specification sheet details PDF, CAD, 137-138Page See more product details.

ProductPackaging

Packing: Inner is Poly foam, out is carton. Then pallet. Carton size: 29*19*19.5CM and 23.5*17.5*8, CM and pallet size is: 215*100*90CM, or as your requirement.

ProductPictures

JX-DIN314 Brass Square wing butterfly nut


JX-DIN314 Brass Square wing butterfly nut
